56
CONNECTORS & RECEPTACLES
SINGLE AND DUAL STACKED USB CONNECTORS PHONE: 773 792-2700
* Please visit the product pages on our website for the most up-to-date product information
SINGLE AND DUAL STACKED USB CONNECTORS
SUSB
Switchcraft introduces single and dual USB connectors. The USB
connectors are fast becoming the industry standard for plug and
play connectivity between PCs and their peripherals. The DUSB
and USB connectors are RAPC mounted, with kinked terminals for
snap-in placement to the PC board. Both meet all Universal Serial
Bus standards.
FEATURES AND BENEFITS
? Snap-in terminals facilitate wave soldering
? Shielded for reduced EMI/RFI emissions
? Dual stacked version increases PC board density
APPLICATIONS
? Personal Computer
? Data Communications
? Medical Equipment
? Test Equipment
? Instrumentation
SPECIFICATIONS
GENERAL
Voltage Rating: 30 VAC (rms) Max.
Current Rating: Signal application only, 1A Max. per contact
Contact Resistance: 25m ohms Max. initial
Temperature Rating: 32°F to 104°F (0°C to 40°C)
Insertion Force: 7.7 lbs Max. (3.5 kg Max.)
Withdrawal Force: 0.8 lb Min. (0.4 kg Min.)
Life: 1500 cycles
MATERIALS
Body: Black, molded thermoplastic, UL 94V-0
Shell: Copper alloy, tin plated
Contact Terminal: Copper alloy, gold plating in mating area,
tin plating on solder tails, all over nickel plating.
DUSB
Part Number
SUSB Single
DUSB Dual Stacked
Description
USB Connector
USB Connector
Note: Special order only, contact factory for details.
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
